3D Wire Panel Is a Visible and Exposed Covering for All Kinds of Walls

3d wire panel attached to exterior wall.

3D wire panel against exterior walls

3D wire panel installed on the roof

3d wire panels are against on every walls in a house.

3D wire panel is against on walls

3D wire panel covering for walls

3D wire panel is also called 3D wall panel, serve as the visible and exposed covering for a wall. Walcoom 3D wire panel is made of three-dimension welded wire mesh and polystyrene panel at the core. It is a rigid spatial structure, preventing the polystyrene panel from shifting.

3D wire panel is a versatile product that used in construction projects. Specifically, it allows for used in floors, walls, partitions, roof and stairs. It is functional and decorative, not only providing insulation and soundproofing but also reducing the 45% cost of construction.

3D wire panel in wall construction features plenty of advantages. On one hand, the metallic welded wire mesh is cost-effective and recyclable. On the other hand, it is lighter than ceramic tiles and concrete but durable. Walcoom 3D panel can be finished by one side if the other side is against a brick or concrete wall. The panel can be cut or drilled holes to fit electric outlets or other devices.

Specification

Material

Low carbon steel, expanded polystyrene, stainless steel.
3D panel dimension
- Wire diameter: 2 mm, 2.5 mm, 3 mm, 3.5 mm, 4.5 mm.
- Length: 2 m, 3 m, 6 m.
- Width: 1 m, 1.15 m, 1.2 m.
- Thickness: 50 mm (for walls), 100 mm (for the internal load-bearing walls), 120 mm (for exterior wall).
- Weight: 25 kg (3 × 1.2 m panel).
- Mesh size: 50 × 50 mm, 50 × 100 mm, 100 × 100 mm.
Diagonal wire
- Wire diameter: 3–4 mm.
- Step laterally: 100 mm or 200 mm.
- Step longitudinally: 100 mm or 200 mm.
- The distance between the mesh and polystyrene: 16 mm (for walls), 20 mm (for load-bearing walls).
- The number of diagonal bracing rods: 100 pieces per square meter.
Expanded polystyrene
- Thickness: 50 mm, 100 mm, 120 mm, 130 mm, 150 mm.
- Denseness: 15–25 kg/m³.
Finish
- Outer layer of shotcrete 50–60 mm (class not lower than B20).
- Inner layer of shotcrete 50–60 mm (class not lower than B20).
Package

A certain amount of 3D wire panels packed in waterproof cases.
